1000-1200mm Plastic HDPE Pipe Welding Machine With Crane Hot Melt Machine WP1200A-Crane
- Model: WP1200A with Crane
- Welding range：1000-1200mm
- Applicable materials：HDPE /PP/ PVDF
- Certificate: ISO 9000/ SGS / CE
- G.W./N.W.: 2928/ 2579kgs
- Volume: 11.87CBM
- Warranty: 18 months
1000-1200mm Pipe Butt Welding Machine With Crane WP1200A
- The WP1200A butt fusion machine is a multi-purpose machine that has been specifically designed to weld pipes with diameters ranging from 1000mm to 1200mm. It is capable of butt fusion welding pipes and fittings of all pressure levels. This butt welding machine with high welding precision, ensures the quality of welded joints.
- The WP1200A butt fusion welding machine is commonly used in the fields of municipal engineering, building construction, water supply and drainage pipe installation and maintenance. In pipeline connection, repair and renovation projects. Suitable for PE, PP, PVDF.
- This 1000-1200mm hdpe pipe jointing machine Integrated die casting aluminum frame, a high-strength steel base with cylinder, provides stable heavy-duty performance.
- Heating plate with high quality PTFE coating, enables swift temperature control.
- Hydraulic station of integrated enclosure shielding splash & dirt
- The hdpe butt welding machine rapidly heats and melts the weld material, ensuring a strong and airtight welded joint. The heat fusion welding machine is easy to operate and maintain, and suitable for on-site construction and small projects.
| Model | WP1200A-Crane |
| Welding Range | 1000-1100-1200mm (630-710-800-900mm is optional) |
| Power Supply | 380V/50HZ, 3PH |
| Total Power | 30.5KW |
| Heater | 22.5KW |
| Trimmer | 4KW |
| Hydraulic Station | 4KW |
| Pressure Range | 0-12 MPa |
| Max Temp | 270ºC |
| Temperature Deviation | ±7ºC |
| Hydraulic oil | L-HM46 |
| Piston Area | 45.94 CM2 |
